PGL-plus-P
Universal gripper : Universal 2-finger parallel gripper with a large jaw stroke, integrated sensor system and high payload due to use of a multi-tooth guidance
Advantages – Your benefits
- Secure, certified gripping force maintenance, GripGuard
Holds the gripped workpiece safely and also ensures a permanent gripping force of min. 80% in case of pressure drop. It also ensures that no dangerous, spontaneous jaw movements can occur in the event of a pressure drop.
- Integrated sensor system
for precise and process-reliable monitoring of the complete gripper stroke via IO-Link
- Large jaw stroke
enables flexible handling of a wide range of parts
- Dirt protected
due to IP 64 as standard and the metal-encapsulated, additionally sealed design at the base jaws
- Robust interior multi-tooth guidance
for high moments and use of long gripper fingers
- With food-compliant lubrication as standard
as a solution for an easy entry into medical technology, lab automation, pharmaceutical and food industry. The requirements of EN 1672-2:2020 are not fully met.
- Fastening on two gripper sides in four screw directions
for universal and flexible gripper assembly
- Air supply via hose-free direct connection or screw connections
for universal and flexible gripper assembly
